The thermosensitive element of the bimetallic sheet type steam trap is a bimetallic sheet cast together by a special process with two different expansion rates of metals. The bimetallic sheet expands after being heated, causing bending due to different expansion rates. Utilizing this characteristic to make a thermosensitive element for a steam trap, it plays a switching role. The bimetallic plate type steam trap is divided into non online adjustable (BK, CS17H, and CS47) and online adjustable (adjustable bimetallic plate type TB).

◆The discharge temperature can be adjusted online, and the installation posture is free.

◆ Utilize high-temperature condensed water to form a water seal, effectively reducing steam leakage.

◆ Sensitive action, resistant to water hammer, and no noise.

◆ Simple structure, easy to maintain and repair.

◆ Used for steam main pipes, sub cylinders, steam tracing pipelines, radiators, low-temperature heating tanks, sandwich pots, etc.

◆Suitable for high-temperature steam pipelines, sub cylinders, etc.
