Stainless steel zero residue sight glass
Product overview
Shell material: carbon steel WCB, stainless steel 304, 321, 316, 316L
Window material: tempered borosilicate glass, quartz glass
Working temperature (℃): 0~250, 0~800
Nominal pressure (MPa): 0.6-1.6, 0.6-2.5
Seal material: nitrile rubber, polytetrafluoroethylene
Connection form: threaded connection, flange connection
Permissible sudden change temperature:<60 ℃
Product Detail
Stainless steel zero residue sight glass is one of the main accessories on industrial pipeline devices. In the pipelines of industrial production devices, the sight glass can observe the flow and reaction of liquids, gases, steam and other media in the pipeline at any time, playing a role in monitoring the process.
